Operation with the mobile fertiliser test ki
Mobile fertiliser test kit DB 538.1 04.08
43
Example 2:
0
100
200
%
I
I
II IIIII IIIIV IV
I
I
II IIIII IIIIV IV
IIIIIIIV
Fig. 11
The selected spreading vane position is not correct as the difference
among the individual fertiliser levels in the four funnel halves is too
big.
In the spreading test hall a spreader which had been set in this way
would result in the illustrated spread pattern.
• Too much fertiliser in the implement's centre, too little fertiliser
within the overlapping range.
7,5
9,5
10,5
7,5
