Ambient Weather WS-7079 User Manual

Version 1.0 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 6
3.4.2 Sensor Array
Figure 2
No
Description
No
Description
1
Antenna
9
Wind vane
2
Rain collector
10
Red LED indicator
3
UV / light sensor
11
[RESET] button
4
Mounting pole
12
Battery door
5
Mounting base
13
Mounting clamp
6
Balance indicator
14
Rain sensor
7
Wind cups
15
Tipping bucket
8
Radiation shield
16
Drain holes
3.5 Powering Up
3.5.1 Power Up Sequence
Note: The power up sequence must be performed in the order shown in this section sensor array
FIRST, display console SECOND) to avoid sensor synchronization time out.
The Outdoor Sensor Array:
1. Unscrew the battery door at the bottom of the sensor array and insert 3 x AA batteries
