Ambient miniVES - Technical Data; Minives 2001 L, 4001 L, 4002 L

19
6. Technical data
6.1 miniVES 2001/4001/4002 L/N, 4002LNR
Model
miniVES
2001L, 4001L, 4002L
miniVES
2001LN, 4001LN,
4002LN, 4002LNR
Power supply 230V AC, IEC C14 3pin terminal
Power consumption Up to 600 W (depending on conguration)
Number of control slots 4
Message storage
SD HC cards with capacities up to 32GB supported
The included 512MB SLC SDHC card provides more
than 20 min of message time
LCD display 4,3” LCD touch screen
DSP Implemented 3 band parametric EQ
Number of audio inputs 1
Type of audio inputs Unbalanced
Connector type 3 pin phoenix connector
Frequency response 40 Hz… 20 kHz (@1dB) / 400 Hz… 8 kHz (@0,1dB)
Input impedance 250 Ω
Maximum input voltage ≤ 3 Vrms
Number of outputs 1
Type of outputs Balanced
Connector type 3 pin phoenix connector
Frequency response 40 Hz… 20 kHz (@1dB) / 400 Hz… 8 kHz (@0,1dB)
