Compact Voice Alarm System
User Manual
24
6.3 midiVES 8003LNR , 8003LN
Model midiVES 8003LNR midiVES 8003LN
Power supply 230 V AC, IEC C14 3pin terminal
Power consumption Up to 1600 W (depending on conguration)
Number of control slots 4
Message storage
SD HC cards with capacities up to 32 GB supported
The included 512 MB SLC SDHC card provides more than 20 min
of message time
LCD display 4,3” LCD touch screen
DSP
Input EQ, outputs EQ, Feedback eliminator and audio limiter,
delay up to 30000 ms
Number of audio inputs 1
No of speaker lines 16
No of control inputs 7
Control by Programmable 4 buttons and color touch screen
No of relay outputs 1x NC, 2x NO
Switching current (Max.) 1 A peak *
Switching voltage (Max.) 50 V AC/DC peak *
Switching power (Max.) 30 W *
No of messages played
at the same time
3
Connector type 3 pin phoenix connector
Frequency response 20 Hz - 22kHz (+0,5 / -3dB) Rated power
Input impedance 250 Ω
