Compact Voice Alarm System
User Manual
22
6.2 midiVES 8003R
Model midiVES 8003R
Power supply 230V AC, IEC C14 3pin terminal
Power consumption Up to 1600 W (depending on conguration)
Number of control slots 4
Message storage
SD HC cards with capacities up to 32 GB supported
The included 512 MB SLC SDHC card provides more than 20 min of
message time
LCD display None
DSP
Input EQ, outputs EQ, Feedback eliminator and audio limiter,
delay up to 30000 ms
Number of audio inputs 1
No of sp eaker lin es 16
No of control inputs 7
Control by Programmable 4 buttons and color touch screen
No of relay outputs 3
No of messages played
at the same time
3
Connector type 3 pin phoenix connector
Frequency response 20 Hz - 22kHz (+0,5 / -3dB) Rated power
Input impedance 250 Ω
Maximum input
voltage
≤ 3 Vrms
Rated output voltage 100Vrms / 20 Ω, THD+N < 1%
