23
Total Harmonic
Distortion + Noise
(THD+N)
< 0,1%
Signal to Noise Ratio
(SNR)
> 76dB
Data communication
Standard communication:
Ű 1000BASE-TX/RJ45 CAT5E cables – 2 ports available on the
connector panel
Ű 100BASE-TX/RJ45 CAT5 cables – 1 port available on the connector
panel, forconnections with an external network
Communication with
PC
PC software: RJ45, twisted pair connection TIA/EIA568-B via Ethernet
protocol
Operating temperature -5°C / +40°C
Operating humidity 15% to 80% (non-condensing)
Storage temperature -20°C / +70°C
Storage humidity 15% to 80% (non-condensing)
Case material and nish Steel with powdercoat nish
Dimensions 439 (W) × 176 (H) × 354 (D) mm
Finish Black
Mounting method 19’’ rack or desk top
Ingress protection IP30
Weight 13,5 kg
Accessories Battery cable, AC power connector, Handheld Microphone
Protection Over-temperature, short circuit, overload, ground leakage
