Page 23
6.2-12 Pull the lung plate a short distance from the
monitoring instrument.
6.2-7 Lift the spring free of the lung plate.
6.2-9 Press down both sides of the lung plate while
keeping the opposite end raised. Maintain pressure on
the plate and pull free in the direction away from the
monitoring instrument.
6.2-11 Lift out the stomach plate with the foam nylon
pad/pads.
6.2-8 Stretch the spring and hook it onto the edge of
the opening in the black base plate.
6.2-10 Release the connecting piece belonging to the
stomach bag by pressing downwards and pushing in the
direction of the instrument.
