www.amcelettronica.com 3
ELECTRICAL SPECIFICATIONS
X412 X412 V X824 X824 V X864 X864 V
K4 K4 V K8 K8 V K8 PLUS K8 PLUS V
Power supply 230 VAC -15% + 10% 50Hz
Protection fuse F500mAL 250V
Output voltage 13.8 V
Voltage range 9 - 16 V
Max absorption 0.1A
Board consumption 87mA@18V~ 90mA@18V~
Max output current 1.1A
Max ripple voltage 400mV
Max battery recharge current 500mA
Back-up battery 12V 7Ah 12V 17Ah
Max load terminal current 500mA 0.9A
Power supply type (EN50131) Type A
Dimensions H = 255mm - L = 300mm - D = 88mm
Weight 1.5 kg
Temperature -10 °C - + 40 °C
Maximum humidity 75% (non-condensed)
SPECIFICATIONS
WARRANTY
AMC Elettronica guarantees a product free from manufacturing defects.
As the product is not installed by the manufacturer and can be used together with other products not made by
AMC Elettronica, the manufacturer does not guarantee and is not responsible for damage and/or theft or other
types of problems deriving from incorrect installation and/or system configuration.
The guarantee therefore does not cover:
• improper use of the equipment
• programming errors or negligence on the part of the installer
• manipulation and vandalism
• wear of the product
• lightning, floods, fire
AMC Elettronica reserves the right to repair or replace the defective product within the established limit of 24
months. Any use other than that indicated in this manual will invalidate the warranty.
The installation must be performed to a professional standard by specialist personnel.
X-XV Series / K-KV Series user manual
