AMD Hudson M1 Chipset User Manual

11
(3)TX-RXCOM Header (4-pin): TX-RXCOM1
TX-RXCOM1 Header
Pin 1
TXDN RXDN
TXDP
Pin 2
RXDP
(4) USB Port Headers (9-pin): USB1/USB2
USB Port Header
VCC
Pin 1
-DATA
GND
+DAT A
VCC
NC
-DATA
GND
+DATA
(5)Front Panel Header (8-pin): JW_FP1
HDLED
RESET
VCC5
GND
VCC5
PWR LED
PWRBTN
PWRBTN PWRLED
HDDLE
RSTS W
GND
JW FP1
Pin 1
