12
(6) CIR Header (4-pin): CIR
CIR Header
1 4
5VSB
CIR
_
RX
G
ND
CIR LED
(7) GPIO Header (10-pin): GPIO1
GPIO Header
GP3O
GP31
2
Pin 1
GP32
GP34
GP36
GND
GP33
GP 35
GP37
VCC5
(8) SYSFAN Header (3-pin): SYSFAN1
Fan Header
13
VCC12
V
GNDDET
