Table 18: Transceiver Module Control Signals (cont'd)
Signal Name Feature Notes
Schematic
Page
SFPDD1_CH0_TXFAULT Module to U1 - fault condition
detected
U1 Bank 709 6, 63
SFPDD1_CH0_TXDISABLE U1 to module - transmitter disable U1 Bank 709 6, 63
SFPDD1_CH0_SPEED1 Module receive rate selection Float on board 63
SFPDD1_CH0_SPEED2 Module receive rate selection Float on board 63
SFPDD1_CH0_RXLOS Module to U1 - RX signal loss U1 Bank 709 6, 63
SFPDD1_CH1_TXFAULTDD U1 to module - transmitter disable U1 Bank 709 6, 63
SFPDD1_CH1_TXDISABLEDD Module to U1 - fault condition
interrupt/detected
U1 Bank 709 6, 63
SFPDD1_CH1_SPEED1DD Module receive - rate selection Float on board 63
SFPDD1_CH1_SPEED2DD Module receive - rate selection Float on board 63
SFPDD1_CH1_RXLOSDD Module to U1 - RX signal loss U1 Bank 709 6, 63
SFPDD1_MOD_ABS Module to U1 - module absent U1 Bank 709 6, 63
SFPDD1_LPMODE U1 to module - low power mode Float on board 63
SFPDD1_RESETL U1 to module - complete module reset U1 Bank 709 6, 63
SFPDD2_I2C_SDA Two-wire interface data U322 I2C MUX 56, 63
SFPDD2_I2C_SCL Two-wire interface clock U322 I2C MUX 56, 63
SFPDD2_CH0_TXFAULT Module to U1 - fault condition
detected
U1 Bank 709 6, 63
SFPDD2_CH0_TXDISABLE U1 to module - transmitter disable U1 Bank 709 6, 63
SFPDD2_CH0_SPEED1 Module receive rate selection Float on board 63
SFPDD2_CH0_SPEED2 Module receive rate selection Float on board 63
SFPDD2_CH0_RXLOS Module to U1 - RX signal loss U1 Bank 709 6, 63
SFPDD2_CH1_TXFAULTDD U1 to module - transmitter disable U1 Bank 709 6, 63
SFPDD2_CH1_TXDISABLEDD Module to U1 - fault condition
interrupt/detected
U1 Bank 709 6, 63
SFPDD2_CH1_SPEED1DD Module receive - rate selection Float on board 63
SFPDD2_CH1_SPEED2DD Module receive - rate selection Float on board 63
SFPDD2_CH1_RXLOSDD Module to U1 - RX signal loss U1 Bank 709 6, 63
SFPDD2_MOD_ABS Module to U1 - module absent U1 Bank 709 6, 63
SFPDD2_LPMODE U1 to module - low power mode Float on board 63
SFPDD2_RESETL U1 to module - complete module reset U1 Bank 709 6, 63
SFPDD3_I2C_SDA Two-wire interface data U322 I2C MUX 56, 64
SFPDD3_I2C_SCL Two-wire interface clock U322 I2C MUX 56, 64
SFPDD3_CH0_TXFAULT Module to U1 - fault condition
detected
U1 Bank 710 6, 64
SFPDD3_CH0_TXDISABLE U1 to module - transmitter disable U1 Bank 710 6, 64
SFPDD3_CH0_SPEED1 Module receive - rate selection Float on board 64
SFPDD3_CH0_SPEED2 Module receive - rate selection Float on board 64
SFPDD3_CH0_RXLOS Module to U1 - RX signal loss U1 Bank 710 6, 64
Chapter 3: Board Component Descriptions
UG1582 (v1.0) February 21, 2023 www.xilinx.com
VPK180 Board User Guide 61
