Ameri-Shred 2 Series - Bearing Assembly

16
AMS-1000 Hard Drive Shredder Manual 2016 v.1
ITEM QTY PART # DESCRIPTION
1 1 34664 ADJUSTABLE SIDE WEAR PLATE
2 1 34663 FIXED SIDE WEAR PLATE
3 1 34647 BEARING LOCK WELDEMENT DRIVE SIDE
4 1 34648 IDLE SIDE BEARING BLOCK WELDMENT
5 4 34659 TIE BAR
6 2 34809 WEARPLATE FILLER PLATE
7 2 112410 KEYSTOCK SPUR GEAR
8 1 112411 REDUCER KEY - FULL LENGTH KEYWAY
9 8 34512 WASHER FOR TIE BAR
10 2 34783 BEARING BLOCK SS SHEET
11 4
112490 ROLLER BEARING
12 1
34362 LOWER MAIN SHAFT
13 4
112492 WASHER
14 4
112491 NUT
15 1
112470 UPPER SHAFT
16 4
A82 SNAP RING
17 2
112403 SPUR GEAR
BEARING ASSEMBLY - 1-1/2”, 1” AND 3/4” SHRED WIDTH
