21
Service Department: 888.270.6879
HD MODELS
CUTTER HEAD ASSEMBLY - 3/4” SHRED WIDTH
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 1 33584 DRIVE BEARING BLOCK 10 4 33620-.75 COMBER TIE BARS
2 1 33585 IDLE BEARING BLOCK 11 2 33619-.75 WEAR BLOCK
3 1 N/A REDUCER: CONSULT FACTORY 12 3 33617-.75 IDLE SHAFT CUTTER
4 1 33615 DRIVE SHAFT 13 4 33616-.75 DRIVE SHAFT CUTTER
5 1 33618 IDLER SHAFT 14 5 33616-.75 SHAFT HEX SPACER
6 4 111907 BEARING 15 2 33663-.75 SHAFT HEX SPACER
7 2 33625 END PLATE 16 2 110016 SPUR GEAR
8 1 33772 SIDE PLATE 17 7 33925 COMBER WELDMENT
9 1 33772 SIDE PLATE OPTIONAL
