Ameri-Shred Series 1 - Cutter Assembly - Ssd Models

22
Service Department: 888.270.6879
SSD MODELS
CUTTER HEAD ASSEMBLY - 3/8” SHRED WIDTH
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 1 33584 DRIVE BEARING BLOCK 13 2 - SPUR GEAR
2 1 33585 IDLE BEARING BLOCK 14 6 34267 CUTTER STYLE 1
3 1 N/A REDUCER: CONSULT FACTORY 15 5 34268 CUTTER STYLE 2
4 1 33615 DRIVE SHAFT 16 4 34269 CUTTER STYLE 3
5 1 33618 IDLER SHAFT 17 13 34276 INSIDE SHAFT SPACER
6 4 111907 BEARING 18 30 34575 INSIDE TIE BAR SPACER
7 1 34449 CUTTERHEAD END PLATE REAR 19 7 34576 REAR COMBER
8 1 34448 CUTTERHEAD END PLATE FRONT 20 6 34577 FRONT COMBER
9 1 34462 SIDE PLATE SPUR GEAR SIDE 21 2 34513 OUTSIDE SHAFT SPACER
10 1 34463 SIDE PLATE DRIVE SIDE 22 2 34498 OUTSIDE COMBER
11 4 33620 TIE BARS 23 2 33598 WEAR BLOCK COMBER
12 2 34514 WEAR BLOCKS
