Ameri-Shred Series 1 - Electrical Installation; Nameplate (Log Shredder Specifics)

4
Service Department: 888.270.6879
All electrical installaon and service must be accomplished by a qualied electrician. Follow all naonal and local
electrical codes and ordinances.
“WARNING”
LOCK POWER IN OFF POSITION
 All internal wiring has been factory installed and tested prior to shipping. Electrical installaon consists of
providing adequate machine power only.
 Check building service to ensure the correct voltage is available and that those current requirements can be
met according to nameplate located on the rear panel of the machine. Record the nameplate informaon in
the space below.
 Install receptacle (provided on 3-phase models only) to properly protect building’s circuit. Select appropriate
wire size and current protecon to accommodate current requirements as shown on nameplate. Plug in
power cable.
 Clear all personnel from machine area. Ensure machine is clean and no tools, rags, or debris have been le
on or near cuers or drive mechanism.
 Turn building service drop power on. Check voltage at installed receptacle.
 Ensure area is clear. Turn key switch to the ON posion. Jog reverse. Check for proper motor rotaon. If
running in reverse, unplug power cable. Check that power is OFF with voltage meter at panel. Remove any
two power wires from the motor starter, reverse them, and reconnect.
 Clear area, turn on power and recheck motor rotaon.
 Electrical installaon is complete.
 Replace all guards.
ELECTRICAL INSTALLATION
MODEL NO. ___________________________________
________________
HORSEPOWER
SERIAL NUMBER ______________________________
_______________
JOB NUMBER
________________ VOLTAGE _______________ PHASE __________ CYCLE A.C.
___________________ AMPS SERVICE DEPARTMENT: 888.270.6879
NAMEPLATE - LOG YOUR SHREDDER SPECIFICS HERE
