Ameri-Shred Series 1 - Cutter Assembly - Hd Models

20
Service Department: 888.270.6879
HD MODELS
CUTTER HEAD ASSEMBLY - 1-1/2” SHRED WIDTH
ITEM QTY PART # DESCRIPTION ITEM QTY PART # DESCRIPTION
1 1 33584 DRIVE BEARING BLOCK 11 1 33587 SPACER
2 1 33585 IDLE BEARING BLOCK 12 2 33663 SPACER
3 1 N/A REDUCER: CONSULT FACTORY 13 2 33772 SIDE PLATE
4 1 33615 DRIVE SHAFT 14 1 33772 SIDE PLATE
5 2 33616 DRIVE SHAFT CUTTER 15 2 33625 END PLATE
6 1 33617 IDLE SHAFT CUTTER 16 2 110016 SPUR GEAR
7 2 33619 WEAR BLOCK 17 2 34464 WEAR BLOCK COMBER
8 1 33618 IDLER SHAFT 18 2 33740 COMBER WELDMENT
9 4 111907 BEARING 19 1 33739 COMBER WELDMENT
10 4 33620 COMBER TIE BARS
