20 Class 2 Compressor Owner’s Manual
COMPRESSOR
RETURN
PRESSURE
AUXILIARY
COOLER
SINGLE
HYDRAULIC
PUMP
SUCTION PORT
FILTER
FILTER SCREEN
HYDRAULIC
RESERVOIR
Typical Hydraulic Circuit for Compressor
with Auxiliary Cooler
