2 Class 2 Compressor Owner’s Manual
Specifications
• Model: 200
• Weight: 60 lbs (SHD-30: 165 lbs)
• Delivery: 13 CFM @ 100 PSI
• Maximum Working Pressure: 150 PSI
• Dimensions: (SHD-30) 26”L x 14.5”W x 17”H
• Electrical: 12 VDC
• Oil Capacity: 24 Ounces
• Cylinders: Two Cylinder(Single Stage)
• Maximum Compressor Speed: 1300 RPM
• 7 GPM Hydraulic System • 1800 PSI System Pressure
• 2500 PSI Pressure Relief Setting • 12 VDC Solenoid Control Valve
• All Steel Plumbing W/ JIC Fittings • Oil Cooler
• 12 Volt Cooler Fan • 6061 Aluminum Manifold
• Direct Drive Coupling • Air Pressure Control Valve
SHD-30 Drive System Description
• Cast Iron Crankcase Casting • Heavy Duty Journal Bushings
• Cast Iron Cylinder Head • Heavy Ductile Iron Crankshaft
• High Temperature Precision Pistons • Micro-honed Connecting Rods
• Stainless Steel Reed Valves • Pressure Lubricated System
Compressor System Description
General Specifications
