American Eagle SHD-60 - Head Options

12 Class 4 Compressor Owner’s Manual
/+.!:>398=
#5808
Aluminum Air Cooled
Imbedded Filter & 3/4”
Threaded NPT Discharge
#C1632
Aluminum Water Cooled
3/4” Threaded Inlet & 3/4”
Threaded NPT Discharge
#22996
Cast Iron Air Cooled
Imbedded Filter & 3/4”
Threaded NPT Discharge
with Head Unloader Ports
#C1631
Aluminum Water Cooled
Imbedded Filter & 3/4”
Threaded NPT Discharge
#15195
Cast Iron Air Cooled
3/4” Threaded Intake Port
on Top of Head with
3/4” Discharge Port
#3897
Cast Iron Air Cooled
3/4” Threaded Inlet & 3/4”
Threaded NPT Discharge
#23039
Cast Iron Air Cooled
3/4” Threaded Inlet & 3/4“
Threaded NPT Discharge
with Head Unloader Ports
