American Panel IC+ - Operational Features; Panic Alarm; Door Open Alarm; Door Frame Heater and Window Heater Control

3
Defaultsetpoints:
 HighAlarmTriggerPoint (AH) LowAlarmTriggerPoint
(AL)
AlarmDelay
(AD)
Cooler 45
o
F 32
o
F
40Minutes
Freezer 20
o
F ‐25
o
F
BeerCooler 34
o
F 30
o
F
4 PanicAlarm
PanicalarmisanoptionalfeatureonAmericanPanelwalk‐ins.IfequippedwithaPanicalarm,thewalk‐incabinetwillhavean
illuminatedredpushbuttoninstalledontheinteriorofthecabinetandanalarmbuzzerwithLEDlightinstallontheexteriorofthe
cabinet.
Totriggerthealarm,pushtheilluminatedredbuttonmountedinsidethewalk‐incabinetandanaudio/visualalarmbuzzerwill
illuminateandsoundthealarmandtheIC+controllerwilldisplaythepanicalarmmessage.IfIC+isconnectedtothelocalWi‐Fi
network,andsetupassuch,itwillsendanalarmmessageviae‐mail.
Toclearthealarm,pushandreleasethepanicbuttontodepressandthenpressthealarmmutebuttonontheIC+.
5 DoorOpenAlarm
IC+controllersmonitorthestatusofthedoor.Ifthedoorisnotfullyclosedorifleftopenformorethanthepre‐settime(5minutes
bydefault)theIC+controllerwilldisplaythealarmmessageandtheonboardbuzzerwillsound.IfIC+isconnectedtothelocalWiFi
network,itwillsendanalarmmessageviae‐mail.
Close the door to reset the alarm.
6 DoorFrameHeaterandWindowHeaterControl
ICcontrollerswitchesonthedoorframeheaterandthewindowheater(ifsoequipped)whentheairtemperaturedrops
belowthepresetthresholdof45
o
Fandthencyclesthemonandoffbasedonatimecycle.Oncoolers,bydefault,theheatersstays
onfor35%ofa6‐minutecycleandthenstaysofffor65%,thecyclewillrepeat.Thealarm’ssetpointsanddelaytimesarefully
programmabletouser’sneeds.
Defaultsetpoints:

 HeatersOn(Pr) HeatersOff Heatersswitchedonbelow:
(tP)
Cooler 35%ofa6‐minutecycle 65%ofa6‐minutecycle
45
o
FFreezer 100%ofa6‐minutecycle 0%ofa6‐minutecycle
BeerCooler 65%ofa6‐minutecycle 35%ofa6‐minutecycle
