11
MENU 4.8
DB Toilet
From MENU 4.4
DETEC. INTERVAL
= 3 Sec
Press up or down to adjust the
user detection activation time
RINSE START INT
= 7
Auto. RINSE
= 55 s
Align the programmer with the sensor
and press to transmit the program, with
the Auto Rinse ON, to the sensor
Auto. RINSE
= OFF
Auto. RINSE
= 72 h
Press up or down to adjust
the Auto Rinse run time
RINSE
= 7 s
Press up or down to
adjust Flush Time
Press up or down to turn
ON the Auto Rise feature
and adjust frequency
Align the programmer with the sensor
and press to transmit the program, with
the Auto Rinse OFF, to the sensor
¾ Dual Flush – Toilet Flush Valve
SHORT RINSING
= 1.5 Sec
Press up or down to adjust
how long to wait after the
user leaves to begin the flush
TIP: The "Short Rinsing" is the is the flush time used
when the user stays in the detection zone for less than 1
minute. – This should be the setting for the lowest of the 2
flush volumes listed for this model flush valve. – See Flush
Valve Settings Chart
TIP: The "Rinse" is the Long Flush Time (Flush Duration) if
the user stays in the detection zone for longer than 1 minute.
See the Flush Valve Settings Chart
TIP: The "DETEC. INTERVAL" (Detection Interval) is how
long a user must be in the detection zone to arm the flush
valve. This eliminates false flushing due to people walking
past the urinals. Recommended setting is 5 sec.
TIP: The "RINSE START INT." (Rinse Start Interval) is
how long after the user leaves the detection zone before
the valve will flush. Recommended setting is 3 sec.
TIP: The "Auto. RINSE" (Sanitary Flush) allows the
flush valve to automatically
flush, after a set time period
of non-use, to maintain the trap seal . This time period
can be set to activate from OFF to 72 hrs (of non-use) in
1 hr increments. You can set the duration of flush time
from 1 sec. to 240 sec. –never more than the fixture
can drain before overflowing! (Recommended
setting is OFF unless prolonged non-use is
expected – then 2 s should maintain the trap seal).
Default Setting: ‘Off’
To Next Page
