Ameriwood HOME 1822096COM - STEP 3; Attaching Support Tubes to Bottom Panel

ameriwoodhome.com
STEP
11
3
3.1 Attach (N) x 2 into (B) with (7), (15) and (16) as illustrated.
Note: DO NOT Tighten the bolt to ensure the assembly successfully in this step.
×8
Tube
You
7
Ø1/4 x 35mm
11
M4 x 57mm
×8
15
×8
16
7
15
16
11
B
N
N
11*Ø6.5
16*Ø6.5
