6.1 Attach (G) into (D) with (5) as illustrated.
6.2 Attach (H) into (E) with (5) as illustrated.
6.3 Attach (C) x 2, (D), (E) into (B) with (9) as illustrated.
×6
Tube
You
5
Ø4.2 x 45mm
8 9
×8
Proper orientation of CAM LOCK
Tip
Quick
Assembly
UNLOCK
LOCK
Wooden Dowel
Hole for wooden dowel
Use one drop of glue in dowel hole.
Glue
D
G
H
E
9
C
E
D
C
B
5
