Ameriwood HOME 1822096COM - STEP 1; Attaching Cam Bolts and Dowels to Panels

ameriwoodhome.com
STEP
9
1
1.1 Cam bolt (10) into (A), (B) as illustrated.
1.2 Insert (1) into (C) x 2 as illustrated.
×8
Tube
You
1
Ø8 x 30mm
8
×19
10
Ø6 x 25mm
A
B
C
x 2
1
10
Wooden Dowel
Hole for wooden dowel
Use one drop of glue in dowel hole.
Glue
