Ameriwood HOME 1822096COM - STEP 4; Attaching Metal Foot Frames

ameriwoodhome.com
STEP
12
4
4.1 Attach (M) into (B) with (7), (15) and (16) as illustrated.
4.2 Attach (M) into (N) with (6), (15) and (16) as illustrated.
Note: DO NOT Tighten the bolt to ensure the assembly
successfully in this step.
Tube
You
×4
7
Ø1/4 x 35mm
11
M4 x 57mm
×8
15
×8
16
×4
6
Ø1/4 x 45mm
16
11
15
7
16
15
6
11
M
M
N
N
B
11*Ø6.5
16*Ø6.5
