AMETEK CTS Automotive Immunity Test Generators
V 1.00 23 / 27
8 Pulse C output
DUT output for pulses C
9 +/- battery input
Either connect a regular car battery 12V or connect a battery simulator, input voltage up to 15V
10 Power switch
To power up and operate the unit. An original car battery (12V) or battery simulator must be connected.
11 BNC connector D
For operational either short circuit to BNC C or connect to a clamp, depending on pulse selection.
12 BNC connector C
For operational either short circuit to BNC D or connect to a clamp, depending on pulse selection.
13 Counter 2
Pulse (relay switching operations) counter for pulses A and C
