Dansensor® ISM-3 EN User Manual 29
P/N 200114-I
09/2021
Technical data
Mains connection 230 VAC (115 VAC) +/- 10%, 50-60 Hz
Consumption max. 70 VA
Mains fuse 0.63 AT at 230 V (1.6 AT at 115 V)
Permissible ambient temp. 0 to 40°C. Less than 95% RH up to 35°C.
during operation Linear RH reduction by 3%RH/°C between 35°C and 40°C
Permissible ambient temp. -20°C to +45°C. Less than 75%RH between 35°C and 45°C.
while stored
IP classification IP 23
Dimensions (HxWxD) Model with remote display :
Control panel: 96 x 96 x 33 mm
Analyser (pressure): 129 x 189 x 139 mm
Analyser (pump): 129 x 189 x 179 mm
Model with built-in display
: 129 x 189 x 179 mm
Weight 5.8 kg
