Ametek MX45-3Pi Installation Manual

Installation Manual - Rev D California Instruments
MX Series 24
P8 / P9
Description
20
300 VRNG: 300 V AC Range Select
21
COM: Common. Signal return.
22
/REM OFF: Remote Off Control not
23
COM: Common. Signal return
24
FLK/BYP: Flicker / Bypass OMNI control
25
/OVL: Overload not
26
CLA: Current Limit A. Programmed current limit reference for phase A
27
CLC: Current Limit C. Programmed current limit reference for phase C
28
CSB: Current Sum Phase B.
29
N/C
30
FLT B: Amplifier Fault Phase B
31
N/C
32
DC: DC mode control
33
INP OFF: Input power control
34
A ERR HI: Error Signal Phase A, high
35
N/C
36
B ERR LO: Error Signal Phase B, low
37
C ERR HI: Error Signal Phase C, high
2.7.2 Analog Input Connector
Input screw-terminal strip. Functions are called out on rear panel decal. Table shows connections
from left to right when standing at the rear of the MX cabinet.
Table 2-5: Analog Interface Connector
Pin
Description
1
RPV HI. INPUT: Analog input for External Modulation
2
RPV Lo. INPUT: return.
3
EXT SYNC HI INPUT: Analog input for external sync mode.
4
EXT SYNC Lo INPUT: return.
5
RI: INPUT: Remote Inhibit. (Contact closure).
6
RI: INPUT: return.
2.7.3 BNC Connectors
BNC connectors. Functions are called out on rear panel decal. Table shows connections from left
to right when standing at the rear of the MX cabinet.
Table 2-6: BNC Connectors
