INSTALLATIONS
MI987 User’s Manual 7
Setting the Jumpers
Jumpers are used on MI987 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on MI987 and their respective functions.
Jumper Locations on MI987 .................................................................. 8
JP1: COM1 RS232 RI/+5V/+12V Power Setting .................................. 9
JP8: Flash Descriptor Security Override (Factory use only) .................. 9
JBAT1: Clear CMOS Contents ............................................................ 10
J15: DP++ Select ................................................................................. 10
JP10: Power On Type .......................................................................... 11
