AMI MI987 - M1987 Specifications

INTRODUCTION
2 MI987 User’s Manual
MI987 Specifications
Product
Name
MI987AF (Q87)
MI987EF (H81)
MI987AF-W (Q87) [Optional for iBASE SG]
Form Factor
Mini ITX
CPU Type
- Intel
®
4
th
Generation Core
TM
DT i7/i5/i3 processors (22nm monolithic)
**Recommend to use low power DT CPU @ TDP 35W/45W**
CPU Speed
Up to 2.7GHz
Cache Size
Up to 8MB
CPU Socket
LGA1150 (Socket H3)
Chipset
Intel
®
Q87 PCH [MI987AF/MI987AF-W]
Intel
®
H81 PCH [MI987EF]
Package =23 mm x 22 mm, 0.65 mm ball pitch
BIOS
AMI BIOS
Memory
Intel
®
4
th
Gen Core
TM
DT processors integrated memory controller,
- DDR3-1600 MHz@1.5V
- SO-DIMM x 2, Max. 16GB (Non-ECC) [Horizontal type]
VGA
Intel
®
4
th
Gen. Core
TM
DT processor integrated HD Gfx, supports 3
independent displays, Direct X 11.1, OpenGL 3.2, Open CL 1.2
- HDMI x 1 (Thru port B, with Level shifter PTN3360D)
- DisplayPort x 1 (Thru port C) **support DP++**
- VGA x 1 (Thru PCH)
LAN
1. Intel® I217LM PHY [MI987AF/-W] or I217V GbE PHY [MI987EF]
2. Intel® I211AT PCIe GbE as 2
nd
LAN
USB
USB 2.0 host controller [Q87/H81 Integrated]
- [MI987AF/-W] : 6 ports via onboard pin header
- [MI987EF] : 4 ports thru pin header
+
2 ports @edge I/O connectors
- 2 ports via MiniPCIe socket
USB 3.0 host controller [Q87 /H81 Integrated] @ edge I/O connectors
- USB 3.0 x 4 ports for MI987AF/-W
- USB 3.0 x 2 ports for MI987EF
Serial ATA
Intel
®
Q87/ H81 PCH built-in SATA controller,
- 2x SATA 3.0 (6Gbps)
- 2 x mSATA [Q87 PCH Port 3/4 for SATA (3.0) or H81 PCH Port 3/4
for SATA(2.0)]
Storage
Device
mSATA x 2 thru full-sized/half-sized Mini-PCIe socket @J12/J13 socket
Audio
Intel
®
Q87/H81 PCH built-in High Definition Audio controller + Realtek
ALC662 w/ 5.1 channels
LPC I/O
Nuvoton NCT5523D (64-pin LQFP [7 mmx7 mm])
- COM #1 (RS232/422/485) support ring-in with power @500 mA
(selectable for 5V or 12V) [EXAR SP339EER1 232/422/485 transceiver x
1 for jumper-less]
- COM #2 (RS232 only)
Hardware Monitor (2 thermal inputs,4 voltage monitor inputs & 2 Fan
headers)
- CPU FAN x 2 (PWM/DC type, 4-pin connector type, auto-detection by
Nuvoton NCT3943S fan controller)
Digital IO
4 in & 4 out
IAMT 9.0
MI987AF/-W only
TPM 1.2
Infineon SLB9655 [MI987AF/-W only]
