AMI MI987 - J5: SPI Flash Connector (Factory Use Only); J6: MCU Flash Connector (Factory Use Only); J7: DC-In Jack (19 V)

INSTALLATIONS
MI987 User’s Manual 17
J5: SPI Flash Connector (Factory use only)
J6: MCU Flash Connector (factory use only)
J7: DC-in Jack (19V)
Pin #
Signal Name
1
Ground
2
Ground
3
DC_IN
4
DC_IN
9
1
10
2
1
4
2 4
1 3
