B. Interrupt Request Lines (IRQ)
Peripheral devices use interrupt request lines to notify CPU for the
service required. The following table shows the IRQ used by the devices
on board.
Level
Function
IRQ0
System Timer
IRQ3
Serial Port #2
IRQ4
Serial Port #1
IRQ 10
Intel(R) 8 Series/C220 Series
SMBus Controller - 8C22
IRQ 13
Numeric data processor
IRQ 16
High Definition Audio Controller
IRQ 16
Intel(R) 8 Series/C220 Series USB
EHCI #2 - 8C2D
IRQ 16
Intel(R) Management Engine
Interface
IRQ 19
Intel(R) 8 Series/C220 Series
SATA AHCI Controller - 8C02
IRQ 19
Intel(R) Active Management
Technology - SOL (COM3)
IRQ 22
High Definition Audio Controller
IRQ 23
Intel(R) 8 Series/C220 Series USB
EHCI #1 - 8C26
