INTRODUCTION
MI987 User’s Manual 3
Expansion
Slots
- PCIe (4x) x1 [Gen 3.0 PEG] [MI987AF/EF]
- MiniPCIe socket x 2 [Full-sized + Half-sized stack type, Full-sized
support PCIe/USB/mSATA, Half-sized support mSATA only]
- Half-sized socket x 1 (3
rd
Mini-PCIe@J16, support PCIe / USB)
Edge
Connectors
DC-Jack x 1(C12135112DC102000P)
DB9+DB15 stack connector for COM #1 + CRT
DP + HDMI stack connector x 1
Dual USB (3.0) + RJ45 stack connector x 2
** For MI987EF, USB 3.0 @ CN7 is USB2 only**
Audio Jack 2 x 1 for MIC-in / Line-out (Reserved for 2-port connector)
Onboard
Header/Conn
ector
2 ports x SATA III [Blue color]
DF-11 2x4 pins pin-header x 3 for 6 ports USB 2.0 (MI987AF/-W)
DF-11 2x4 pins pin-header x 2 for 4 ports USB 2.0 (MI987EF)
DF-11 2x6 pins pin-header x 1 for front panel audio
DF-11 2x5 pins box header x 1 for COM2 (RS232)
2x5 pins pin-header x1 for Digital IO
4 pins mini-type header for SATA device power x 2 [JST type]
2 x 4 pins pin header x 1 for front I/O (2.54 pitch)
Watchdog
Timer
Yes (256 segments, 0, 1, 2…255 sec/min)
System
Voltage
+19V DC-in (±20%)
Other
- LAN Wakeup
- EuP/ErP (MI987EF only, thru Super I/O)
- iSMART function(TI MSP430G2433 MCU)
- Legacy Free from super I/O
- AT24C02C EEPROM [SO8 type] via SMbus
Board Size
170mm x 170mm
Operation
System
Windows 7, Windows 8
