NCT5523D H/W Monitor
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
PC Health Status
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Smart SYS_FAN1 Function
Disabled
Smart CPU_FAN1 Function
Disabled
SYS temp
+33.0 C
CPU temp
+34.5 C
SYS_FAN1 Speed
4066 RPM
CPU_FAN1 Speed
4066 RPM
Vcore
+1.704 V
+1.5V
+1.544 V
AVCC
VSB3
+3.360 V
+3.344 V
Smart SYS_FAN1/CPU_FAN1 Function
This field enables or disables the smart fan feature.
Disabled (default)
50 ℃
60 ℃
70 ℃
80 ℃
90 ℃
Temperatures/Voltages
These fields are the parameters of the hardware monitoring function
feature of the motherboard. The values are read-only values as monitored
by the system and show the PC health status.
