LOOPSENSE EN54 INSTALLATION & COMMISSIONING
10.6.5 Specifications
Mechanical
Dimensions ABS Cabinet: (mm)
Weight (without batteries)
195 (H) x 324 (W) x 52 (D)
2Kg
Environmental
Temperature:
Humidity:
0ºC to +40ºC
25% to 75%
Input Power
Operating Voltage (nominal):
Operating Voltage (minimum):
Quiescent Current @ 26.5VDC:
Maximum Current:
Cabling Requirements:
27VDC
18VDC
12.4mA (back light off, buzzer off)
43.8mA (back light on, buzzer on)
2 core 1.5 to 2.5mm²
27VDC Outputs
Auxiliary 27VDC Distribution:
Cabling Requirements:
24VDC 500mA Monitored
2 core 1.5 to 2.5mm²
Communications
Internal to FACP:
External to FACP:
Cabling Requirements:
Fault monitoring:
Maximum Number of SmartTerminal per FACP:
Maximum Distance (from FACP):
RS485
RS485
Twisted shielded pair plus shield
O/C, S/C
30
1.2Kms.
LCD
4 line X 40 characters – backlight
operation same as for FACP
10.6.6 Operational & Key Features
SmartTerminal has been designed for use with AMPAC’s range of intelligent FACP’s.
 4 line by 40 character LCD with backlight and navigation keys   keys allow the
SmartTerminal to be used for FACP operation and interrogation.
 Buzzer and system Reset.
 Flush or surface mountable enclosure.
 Controls have tactile and audible feedback of operation.
 All terminals cater for 2.5mm cables.
Note: The backlight is only energised when alarms are present, a key has been pressed or
controls enable key switch is enabled
10.6.7 Mechanical
SmartTerminal is supplied in an ABS cabinet and consists of;
The Main Card, with all controls and indicators mounted directly onto it
 1 X Termination Board
 2 X ABS door keys
 2 X 1502 control Enable / Disable keys
 Termination link
