LOOPSENSE EN54 INSTALLATION & COMMISSIONING
The loops consist of a positive and common and are able to source up to 500mA
of current. The loops;
 Operate in single ended and redundant configurations
 Are monitored for over current and short circuit in single ended mode
 Monitored for over current, short circuit and open circuit in the redundant mode.
Note: A loop test function is available via the FACP user interface.
3.1.4 FACP Main Termination Board Inputs & Outputs
1 to 4 Supervised Inputs:
 TB1 6-9.-Programmable digital inputs compatible with voltage free type outputs supervised
for open, short and earth faults. EOL is 10k. I/P4’s configuration can be changed to FARE if
required.
 Inputs default configurations are:
 IP1 Class change
 IP2 Evacuate
 IP3 Fault
 IP4 Reset
1 to 4 Supervised Sounder Outputs:
 TB3 - Programmable Supervised switched 24VDC output sourcing up to 750mA and
supervised for short, open and earth faults. O/P’s are also supervised for overload when
they are ON. EOL is 10K
 Output default configurations are:
 Sounder Outputs 1-4.
1 to 2 Open Collector Outputs:
 Ancillary Output1 TB6/2 – low current (limited to 30mA), activated when there is a fire
condition present on the FACP.
 Ancillary Output2 TB6/3– low current (limited to 30mA); activated when there is an ancillary
condition present on the FACP.
1 to 3 Relay Outputs:
 TB4 – Programmable Voltage free relay contacts. Consists of NC, C and NO contacts.
 Relay default configurations are:
 Fire
 Alarm
 Fault
1 to 2 Auxiliary 24VDC Outputs:
 TB1 3 and 4 & TB5- Programmable, supervised for over current, switched 24VDC output
sourcing up to 1A. Set to continuous as default
