4.3 Mechanical Arrangement
4.3.1 OCS Dimensions
The OCS is available in two sizes: the 2-Way OCS and the 3-Way OCS. These modules are designed
to be stacked on top of each other, allowing the best utilisation of the installation area.
Figure 4.1: 2-Way OCS Dimensions (Pictured with 2 Cassettes Installed)
Figure 4.2: 3-Way OCS Dimensions (Pictured with 3 Cassettes Installed)
683
449
509
683
750
509
