6.5 Protection Element Parameters
There are two distinct groups of parameters:
6.5.1 Outlet Parameters
Outlet Parameters relate to the particular outlet/Protection Element. Examples include the pilot mode,
outlet number and network settings. These are always stored in the Parameter Dongle.
Table 3: Outlet Parameter Descriptions
Name
Description
IP Address Byte 1
IP address for Ethernet communications with the PLC.
IP Address Byte 2
IP Address Byte 3
IP Address Byte 4
Subnet mask Byte 1
Subnet mask for Ethernet communications with the PLC.
Subnet mask Byte 2
Subnet mask Byte 3
Subnet mask Byte 4
Gateway Address Byte 1
Gateway address for Ethernet communications with the PLC.
Gateway Address Byte 2
Gateway Address Byte 3
Gateway Address Byte 4
Pilot mode
Selects the pilot termination method; diode or RTX.
Loss Of Vacuum Level
Trip level for loss of vacuum protection.
Voltage Level
Defines the system voltage level.
SC Output Relay
Selects which output relay the short circuit trips.
6.5.2 Load Parameters
Load Parameters relate to the properties of different loads that may be connected to the Outlet
Cassette. Examples include the motor current, EC trip latch, and remote control. Load parameters can
be stored in the Parameter Dongle of either the RTX (if present) or the Protection Element.
NOTE
Parameters cannot be changed while the Protection Element is running.
