8.1.2 Motor Overload
Table 19: Protection Element Motor Overload Trip Characteristics
Parameter
Action
Power Cycle
Trip Status maintained
Reset
Requires a general reset (and all three measured phase currents must
be below the 100%).
Trip Actions
Open Main Contactor
Prevent Main Contactor from closing
Block restart if the thermal accumulator is not below the selected start
block level.
Active Period
When Over Current curve is set to Motor Overload.
Logging
Always
Parameters
Time Multiplier
Full Load Current
Cooling Multiplier
Monitoring
Phase currents displayed as a percentage of selected full load current
TAC.
This protection scheme uses a simple first order thermal model of the motor to determine the tripping
characteristic. It is fundamentally different to the Over Current protection outlined above in that it all
current levels contribute to the model heating, and the effects of that heating persist in the model, where
as in the Over Currents functions, the trip accumulator resets relatively quickly if the current falls below
the selected full load current level.
The three measured phase currents are squared and added together to provide the heating input into the
thermal model. The cooling is assumed to be proportional to the model’s ‘temperature’ at any given time.
The Thermal Accumulator (TAC) is the model’s ‘temperature’ where 0% represents the motor being cold,
and 100% means the motor has reached its maximum temperature (and is therefore tripped).
The trip time is dependant not only on the present current level, but also the prior current history. Since
motor currents typically vary widely during starting and running, the actual trip time is also variable. To
facilitate co-ordination of the protection with motor capabilities (and upstream protection), the trip time in
seconds for a simple (theoretical) scenario of a fixed overload current of I is given by:
󰇛󰇜 󰇧





󰇨
Where:
t(I) = the idealised trip time,
I = the input current ratio relative to the full load current set point ie per unit current,
TMS = the Over Current Time Multiplier Setting,
Ip = the load current that was flowing (long enough to reach thermal stability) prior to the
overload occurrence.
ln = the natural logarithm.
