4.3.2 FCS Dimensions
The FCS has a very high outlet density, allowing more outlets to be installed with a smaller footprint.
Figure 4.3: FCS Dimensions (Pictured with 5 Cassettes Installed)
4.4 Electrical Installation Information
Refer to drawing OCSE002in APPENDIX B: DRAWINGS for electrical installation information.
450
665
1160
