Protection Element Over Current Time Multiplier Settings (TMS) including nominal trip time in
seconds at 10 PU Current
Value
TMS
10 x trip time
Value
TMS
10 x trip time
Value
TMS
10 x trip time
Ext Inv.
& MOL
Very
Inv.
Ext Inv.
& MOL
Very
Inv.
Ext Inv.
& MOL
Very
Inv.
25
0.32
0.259
0.480
55
3.2
2.59
4.80
26
0.35
0.283
0.525
56
3.5
2.83
5.25
27
0.38
0.307
0.570
57
3.8
3.07
5.70
28
0.42
0.339
0.630
58
4.2
3.39
6.30
29
0.46
0.372
0.690
59
4.6
3.72
6.90
