LED Indicators
(From Top to Bottom)
Power/Logo LED: Indicates when the Range Extender is powered on. The LED will
stay lit when the Range Extender is plugged into a power outlet.
When the WPS or Reset buttons are pressed, the LED will begin to blink.
Wired Port LED: Indicates when a networking device is connected to a wired port
on the bottom of the Range Extender. The LED blinks rapidly when wired data
traffic is transmitted or received.
