LED Indicators
(From Top to Bottom)
Power: Indicates when the High Power Smart Repeater is powered on. The LED will
stay lit when power adapter is plugged into repeater.
Wireless Activity: Blinks rapidly when wireless data traffic is passing through the Smart
Repeater. When there is a problem with the Wi-Fi connection this LED will remain off or
blink steadily.
Wired Devices (1-5): Indicates when a networking device is connected to a wired port
on the back of the High Power Smart Repeater. The LED blinks rapidly when wired data
traffic is transmitted or received.
WPS: Wi-Fi Protected Setup activity. When the WPS mode is activated the WPS LED
blinks as it awaits a connection.
