AmpliVox 116 - Model 116 Max Hearing Levels by Frequency

Page 14 OM006-12 Model 116 Operating Manual
5.2 Maximum hearing levels provided at each frequency
Frequency,
Hz
Air conduction,
dBHL (DD45)
Frequency,
Hz
Air conduction,
dBHL (DD45)
125
70
2000
100
250
80
3000
100
500
90
4000
100
750
100
6000
100
1000
100
8000
80
1500
100
5.3 Physical Data
Display: 2 lines of 24 characters
Battery power (optional): 4x1.5V “C” cells (alkaline recommended)
Mains power: 100-240Vac; 50/60Hz; 0.4A
Dimensions: 270mm long x 175mm deep x 68mm high
Weight (no batteries): 0.75kg (approx)
Safety: IEC 60601-1 (plus UL, CSA & EN deviations)
EMC: IEC 60601-1-2
CE mark: To the EU Medical Device Directive
5.4 Equipment classification
Type of protection against electric shock Powered via SELV
ClassII mains adapter
Degree of protection against electric shock Type B applied part
Degree of protection against ingress of water Not protected
Mode of operation Continuous operation
Equipment mobility Portable
The Model 116 Audiometer is classified as a Class IIa device under Annex
IX of the EU Medical Devices Directive. It is intended for use as a
screening audiometer instrument.
