The relevant part numbers are indicated in Section 12
Note regarding the 6-pin mini DIN connector:
This is a restricted socket for Amplivox use only. No user access is
permitted.
For connected parts marked * only connect the
accessories supplied with the instrument or supplied
by Amplivox or an Amplivox distributor. These parts
have been tested for use with the Model 116
Screening Audiometer for compliance with the
standards IEC 60601-1 and IEC 60601-1-2. The use of
accessories other than those specified may
compromise compliance with these standards. For
other sockets refer to Appendix 2.
2.5 Data transfer to a printer
Please refer to Appendix 2 for important information
regarding the connection of non-medical electrical
equipment to medical electrical equipment
The audiometer can be upgraded with an option to allow connection to
one of three designated portable thermal printers for printing audiometric
test results (see Section 3.6). You must use the designated cable for each
printer, which is supplied with this option.
Upon receipt of the printer it must be initially charged for a minimum of 15
hours prior to use.
2.6 Data transfer to a computer
Please refer to Appendix 2 for important information
regarding the connection of non-medical electrical
equipment to medical electrical equipment
The audiometer is supplied with software to allow connection to a
computer for the transfer of test results (see Section 3.7). You must use
the designated USB cable which is available from Amplivox (see Section
12).
