Chapter 2 Product Overview
CoreModule 420 Reference Manual 15
NOTE The CoreModule 420 is in violation of the PC/104 height limitations in two
places on the bottom of the board. The voltage regulator (U19) exceeds the
allowed height limitation by 0.085 inches and the CompactFlash socket (J12)
exceeds the height limitation by 0.2 inches. See Figure 2-6.
Power Specifications
Table 2-6 provides the power requirements.
Table 2-6. Power Supply Requirements
Parameter Characteristics
Input Type Regulated DC voltages
Input Voltage
Requirements
+5 VDC +/- 5% @ 1.35 Amps (typical)
Operating Power 6.75 Watts (typical)
Note: Current readings were taken with all peripheral devices connected or simulated using the
Windows 2000 operating system.
Environmental Specifications
Table 2-7 provides the most efficient operating and storage condition ranges required for this module.
Table 2-7. Environmental Requirements
Parameter Conditions
Temperature
Operating
+0° to +70° C (32° to 158° F)
Extended (Optional)
–40° to +85° C (–40° F to +185° F)
Storage
–55° to +85° C (–67° F to +185° F)
Humidity
Operating 20% to 80% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, non-condensing
Thermal/Cooling Requirements
The CPU requires a heatsink (provided).
