AMPROBE
DMIII MULTITEST
EN-20
THE PREVIOUS RESULTS CAN'T BE SAVED.

If the value of
Resistance is higher
than 5 (but lower than
99.9) the instrument
emits a long beep and
displays a screen similar
to the screen to the right
LOW 05.06.01
Resistance value higher
than 5

5.17
R+ R-
5.17 5.17
209mA 209mA
AUTO 0.11
Test current
FUNC
CAL
The displayed result can be stored pressing the SAVE key twice (refer to
paragraph 9.1).

If the value of
Resistance is higher
than 99.9 the
instrument emits a long
beep and displays the
screen to the right.
LOW 05.06.01
Resistance value higher
than 99.9
> 99.9
R+ R-
-.-- -.--
---mA ---mA
AUTO 0.11
ATTENTION: Value of
Resistance Out of Range
FUNC
CAL
The displayed result can be stored pressing the SAVE key twice (refer to
paragraph 9.1).
