AMPROBE
DMIII MULTITEST
EN-19
6.1.5. "AUTO", RT+", "RT-" faulty cases

If the instrument detect
the External Power
supply adapter
connected to instrument
will show the message
displayed to the right.
LOW 05.06.01
-
.- -
R+ R-
--- ---
---mA ---mA
 REMOVE POWER
AUTO 0.11
Disconnect the External
Power Supply Adapter
FUNC
CAL

If the terminal voltage is
higher than 15V, the
instrument does not
perform the test and
displays the screen to
the right for 5 seconds.
LOW 05.06.01
-.- -

R+ R-
-.-- -.--
---mA ---mA
 VOLT IN INPUT
AUTO 0.11
ATTENTION: the test was
not performed because of
voltage at the terminal
ends.
FUNC
CAL

In the case that:
R
CALIBRATION
>R
MEASURED
the instrument displays
the screen to the right.
LOW 05.06.01
 0.00
R+ R-
0.00 0.00
219mA 219mA
CAL > RES
AUTO 0.11
ATTENTION:
R
CALIBRATION
>R
MEASURED
FUNC
CAL
