Amprobe PM55A - Capacitance, Resistance, Frequency Specs; Capacitance & Resistance Specs; Frequency Specs

13
Capacitance
Range
1
Accuracy
2
100.0nF, 1000nF, 10.00µF, 100.0µF
3)
±(3.5%+6 dgt)
4
1)
Accuracy below 50nF is not specified
2)
Accuracies with film capacitor or better
3)
Updates > 1 minute on large values
4)
Specified with battery voltage above 2.8 V (half full battery). Accuracy decreases gradually to
12% at low battery warning voltage of approx. 2.4 V.
Resistance
Range
1
Accuracy
2
600.0 Ω ±(2.0%+6 dgt)
6.000 kΩ ±(1.2%+6 dgt)
60.00 KΩ, 600.0 KΩ ±(1.0%+4 dgt)
6.000 MΩ ±(2.0%+4 dgt)
Open Circuit Voltage: 0.4VDC typical
1)AutoTect is for 6.000kΩ ~ 6.000MΩ ranges;
2)Add 40 dgt to specified accuracy while reading is below 20% of range
Frequency
Range
1
Accuracy Specified At
10.00 Hz -30.00 kHz
2
< 2 0 V Sine-rms
10.00 Hz -999.9 Hz
±(0.5%+4 dgt)
< 600 V Sine-rms
1
Sensitivity (Sine-rms):
Hz in Auto-VΩ position:> 3 V
2
Line-level Hz in V position
@ 6.000 V ac range: > 3 V
@ 60.00 V ac range: > 6 V
@ 600.0 V ac range: > 60 V
