Amprobe PM55A - Current, VolTect, Continuity, and Diode Test Specs; Current & VolTect Specs; Continuity & Diode Test Specs

14
DC µA Current
Range
1
Accuracy Burden Voltage
400.0 µA ±(1.5%+3 dgt) 6 mV/µA
2000 µA ±(1.2%+3 dgt) 6 mV/µA
AC µA Current
Range
1
Accuracy Burden Voltage
400.0 µA ±(2.0%+3 dgt) 6 mV/µA
2000 µA ±(1.5%+3 dgt) 6 mV/µA
Voltect
Typical Voltage Bar Graph Indication
20 V to 80 V -
45 V to 125 V - -
70 V to 215 V - - -
120 V to 285 V - - - -
above 170 V - - - - -
Indication: Bar graph segments & audible beep tones proportional to field strength
Detection Frequency: 50/60 Hz
Detection Antenna: Top left corner of the meter
Audible Continuity Tester (600 Ω Range)
Open Circuit Voltage: 0.4 V dc typical
Audible Threshold: >175 Ω ± 125 Ω
Diode Test
Test Current: 0.48 ma typical
Open Circuit Voltage: <1.6 V dc
